VHF MARINE TRANSCEIVER IC-M73
VHF MARINE TRANSCEIVER IC-M73
Slim, Stylish, Powerful VHF with Professional Features
Contact: Lily Zhang
E-mail:sales@allshipparts.com
E-mail:info@allshipparts.com
WeChat:Allshipparts
The last call voice recording function automatically saves the last incoming call for 1 minute. You can also start recording manually. You will not miss an important call.
The built-in bidirectional active noise cancelling reduces background noise to up to 90% and improves both your transmitted voice and incoming call. You will hear better and clearer!
The signal processing technology emphasizes low-pitched sound to provide a rich bass sound for both transmit and receive signals.
The IC-M73 uses a BTL (bridge-tied load) amplifier that doubles the audio output. Its internal speaker delivers a loud 700mW audio output with clear sound.
The IC-M73's 6 Watts of transmit power will provide extended communication range for the user. A large capacity Lithium-Ion battery, BP-245H allows for 17 hours of operation, under normal conditions*.
* Typical operation with 5:5:90 duty ratio. 20 hours for basic version.
The IC-M73 continues to offer Icom's best waterproof protection. The radio has been tested to survive after being submersed in 1.5 m (4.9 ft) depth of water for 30 minutes.
The IC-M73 has a stylish, ergonomic design. A durable and rugged body provides user-friendly operation and long life. A wide viewing angle, high intensity LCD offers bright, easy to read characters.
・ AquaQuake™ prevents audio degradation from a
water-logged speaker
・ Dual/Tri-Watch function for monitoring
Channel 16 and/or call channel
・ 4 level battery indicator
・ Favorite channel and tag scan functions
・ Rapid desktop charger, BC-210, and cigarette
lighter cable, CP-25H, are supplied
・ Optional waterproof speaker-microphones,
HM-167 and HM-202
・ Auto power save function
・ Basic version (no voice recorder, no noise
canceller and no bass boost function) available for limited markets.
・ Supports 4-digit channels
General
|
Frequency range |
Tx |
156.025–157.425 MHz |
|
Rx |
156.050–163.275 MHz |
|
|
Usable channel groups |
INT, USA, CAN, WX channels |
|
|
Type of emission |
16K0G3E (FM) |
|
|
Current drain |
Tx 6 W output |
1.5 A |
|
Rx Max. audio |
450 mA/250 mA |
|
|
Operating temp. range |
–20°C to +60°C; –4°F to +140°F |
|
|
Antenna impedance |
50 Ω |
|
|
Dimensions
(W×H×D) |
52.5×125×30 mm |
|
|
Weight (approximate) |
320 g; 11.3 oz |
|
Measurements made in accordance with TIA/EIA-603. All stated specifications are subject to change without notice or obligation.
Transmitter
|
Output power (Hi/Mid/Low) |
6 W/3 W/1 W |
|
Max. frequency deviation |
±5.0 kHz |
|
Frequency stability |
±10 ppm |
|
Spurious emissions |
–68 dBc typical |
|
Adjacent channel power |
70 dB |
|
Audio harmonic distortion |
10% (at 60% dev.) |
|
Residual modulation |
40 dB |
Receiver
|
Sensitivity |
0.22 µV typical (at 12dB SINAD) |
|
|
Squelch sensitivity |
0.35 µV typical (at threshold) |
|
|
Adjacent channel selectivity |
70 dB typical |
|
|
Spurious response |
70 dB typical |
|
|
Intermodulation |
70 dB typical |
|
|
Hum and noise |
40 dB |
|
|
Audio output
power |
700 mW typical (Internal SP) |
|
Applicable U.S. Military Specifications
Icom makes rugged products that have been tested to and passed the following MIL-STD requirements and strict environmental standards.
|
Standard |
MIL-810 G |
|
|
Method |
Procedure |
|
|
Low Pressure Storage |
500.5 |
I |
|
Low Pressure Operation |
500.5 |
II |
|
High Temperature Storage |
501.5 |
I |
|
High Temperature Operation |
501.5 |
II |
|
Low Temperature Storage |
502.5 |
I |
|
Low Temperature Operation |
502.5 |
II |
|
Temperature Shock |
503.5 |
I-C |
|
Solar Radiation |
505.5 |
I |
|
Rain Blowing |
506.5 |
I |
|
Rain Drip |
506.5 |
III |
|
Humidity |
507.5 |
II |
|
Salt Fog |
509.5 |
- |
|
Dust Blowing |
510.5 |
I |
|
Water Immersion |
512.5 |
I |
|
Vibration |
514.6 |
I |
|
Shock Functional |
516.6 |
I |
|
Shock Transit Drop |
516.6 |
IV |
Also meets equicalent MIL-STD-810-C, -D, -E and -F.
Applicable IP Rating
|
Ingress Protection Standard |
|
|
Water |
IPX8 (Waterproof protection) |
All stated specifications are subject to change without notice or obligation.
Supplied accessories
· Cigarette lighter cable, CP-25H
· AC adapter, BC-123SA/SE*
· Rapid charger, BC-210
· Battery pack, BP-245H
· Belt clip, MB-103
· Antenna, FA-S59V or FA-S64V*
· Hand strap
* May differ depending on version.
