ICOM MF/HF MARINE TRANSCEIVER IC-M710
Simple, Reliable, Worldwide Communications
Contact: Lily Zhang
E-mail:sales@allshipparts.com
E-mail:info@allshipparts.com
WeChat:Allshipparts
Seven characters can be programmed into each memory channel to
conveniently display
station names or ship names for simplified operation.
A large cooling fan system, in combination with the aluminum chassis, allows conditions for transmission at a full 150 W* (PEP) RF output power—even during demanding RTTY (radio teletype) operation.
*60 W (PEP) above 24 MHz bands.
・ General coverage receiver
・ Terminals for frequency/mode control via NMEA
interfacing
・ Automatic tuning function
・ Large, front-mounted speaker
・ Weather fax ready
・ Backlight control
・ CW full break-in and semi break-in
・ 2-tone alarm built-in (Optional depending on
version)
・ 1136 channels available
|
Frequency range |
TX |
1.6–2.9999 MHz |
|
RX |
0.5–29.9999 MHz |
|
|
Power supply requirement |
13.6 V DC ±15% (negative ground) |
|
|
Dimensions
(W×H×D) |
291.4×116.4×315 mm; |
|
|
Weight (approx.) |
7.8 kg; 17.2 lb |
|
|
Current drain (approx.) |
Transmit (High) |
30 A at max. power |
|
Max. audio output |
2.5 A |
|
|
Sensitivity |
J3E,J2B,R3E,A1A (12 dB SINAD) |
0.5 μV |
|
H3E （10 dB S/N） |
3.2 μV |
|
|
Spurious response rejection (1.6-29.999 MHz) |
More than 70 dB |
|
|
Audio output power (10% dist/ 4 Ω load) |
4 W |
|
|
RF output power
(PEP) |
150/60/20 W (below 24 MHz) |
|
All stated specifications are subject to change without notice or
obligation.
Supplied Accessories
· Hand microphone
· DC power cable
· ACC plugs
· Mounting bracket kit
· Microphone hanger
· Speaker plug
· Spare fuses
