ICOM VHF/UHF HANDHELD TRANSCEIVERSIC-F3032 IC-F4032 Series (EUR Version)
Contact: Lily Zhang
E-mail:sales@allshipparts.com
E-mail:info@allshipparts.com
WeChat:Allshipparts
VHF/10-keypadIC-F3032T
VHF/Simple keyIC-F3032S
UHF/10-keypadIC-F4032T
UHF/Simple keyIC-F4032S
SHAPE \* MERGEFORMAT
The IC-F3032T/S series provides outstanding protection against water and dust equivalent to IP67. The IC-F3032T/S series can withstand 1m depth of water for 30 minutes and its dust-tight construction that prevents the ingress of powder dust, sand, mud and other objects.
The supplied waterproof Li-Ion battery pack, BP- 232WP (7.4V, 2350mAh (typ.)), provides 17.5 hours* of operating time. The battery has been designed for reliability in extremely cold environments.
*Tx:Rx:Standby=5:5:90. Power save function ON.
The IC-F3032T/S series has built-in 2-Tone, 5-Tone, CTCSS and DTCS signaling capabilities for group communication or selective calling. When a matched 2-Tone/5-Tone is received, the following actions are programmable for each code.
· Answer back calls
· Beep sounds
· Bell icon
· Radio stun/kill/revive
· Auto TX
· Scan
The following selective calling and ANI features are programmable with the built-in MDC signaling.
· PTT ID
· Emergency (No ACK transmission)
· Radio check (RX only)
· Stun/Revive (RX only)
A red button on the top panel can be used as an emergency button and can be used to transmit an emergency signal. Man down (optional UT- 124R required) and lone worker functions can also be used for the emergency function trigger.
Priority scan allows you to monitor one or two priority channels while scanning other channels. The mode dependent scan automatically changes the scanning list following the operating channel. The Tx channel and talk back functions allow you to make a quick response while scanning.
The IC-F3032T/S series has an internal socket for a variety of option units including voice scrambler, DTMF decoder or man down unit.
· Up to 128 memory channel with 8 zones
· 8-character alphanumeric LCD
· 8 DTMF autodial memories
· Optional HM-168LWP, waterproof speaker-mic
· BIIS PTT ID transmission
· Low battery alert
· 2-step power save
· PC programmable
· Time out timer
· Talk around function
· Surveillance function
|
IC-F3032T/S |
IC-F4032T/S |
|||
|
Frequency
coverage |
136–174MHz |
400–470MHz |
||
|
Number of channels |
128 channels/8 zones |
|||
|
Channel spacing |
25/20/12.5 kHz |
|||
|
Type of emission |
16K0F3E/14K0F3E/8K50F3E |
|||
|
Current drain |
Tx High |
1.5A (at 5W) |
1.6A (at 4W) |
|
|
Rx |
Stand-by |
75mA |
||
|
Max. audio |
250mA |
300mA |
||
|
Dimensions |
53×120×37 mm |
|||
|
Weight (approx.) |
310g (With BP-232WP) |
|||
|
IC-F3032T/S |
IC-F4032T/S |
|
|
RF output power (at 7.2V DC) |
5W, 2W, 1W |
4W, 2W, 1W |
|
Spurious emissions |
0.25μW (≤ 1GHz), 1.0μW (> 1GHz) |
|
|
Frequency stability |
±2.5ppm |
|
|
Audio harmonic distortion |
3% typ. (AF 1kHz 40% deviation) |
|
|
IC-F3032T/S |
IC-F4032T/S |
|
|
Sensitivity at 20dB SINAD |
–4dBμV typ. emf |
|
|
Adjacent channel selectivity (W/M/N) |
75/75/65dB typ. |
75/73/65dB typ. |
|
Spurious response rejection |
70dB min. |
|
|
Intermodulation rejection |
67dB typ. |
|
|
AF output power |
500mW typ. |
|
|
IC-F3032T/S IC-F4032T/S |
||
|
Number of option slots |
1 |
|
|
CTCSS/ DTCS |
encoder |
Available |
|
decoder |
Available |
|
|
2-Tone |
encoder |
Available |
|
decoder |
Available |
|
|
5-Tone |
encoder |
Available |
|
decoder |
Available |
|
|
DTMF autodial |
Available |
|
|
DTMF decoder |
- |
|
|
Voice Scrambler |
Inversion |
- |
|
BllS 1200 |
PTT ID only |
|
|
MPT 1327 |
- |
|
|
LTR™ trunking |
- |
|
|
Man Down function |
UT-124R |
|
|
Intrinsically safe |
- |
|
Icom makes rugged products that have been tested to and passed the following MIL-STD requirements and strict environmental standards.
|
Standard |
MIL-810 F |
|
Low Pressure Storage |
500.5 I |
|
Low Pressure Operation |
500.5 II |
|
High Temperature Storage |
501.5 I |
|
High Temperature Operation |
501.5 II |
|
Low Temperature Storage |
502.5 I |
|
Low Temperature Operation |
502.5 II |
|
Temperature Shock |
503.5 I-C |
|
Solar Radiation |
505.5 I |
|
Rain Blowing |
506.5 I |
|
Rain Drip |
506.5 III |
|
Humidity Induced |
507.5 II |
|
Salt Fog |
509.5 |
|
Dust Blowing |
510.5 I |
|
Immersion |
512.5 I |
|
Vibration |
514.6 I |
|
Shock Functional |
516.6 I |
|
Shock Transit Drop |
516.6 IV |
Also meets equivalent MIL-STD-810 -C, -D, -E and -F.
|
Ingress Protection Standard (IC-F3032T/S/F4032T/S, BP-232WP & HM-168LWP) |
|
|
Dust & Water |
IP67 (Dust-tight and waterproof protection) |
All stated specifications are subject to change without notice or obligation.
