ICOM MF/HF MARINE TRANSCEIVER GM800
ICOM MF/HF MARINE TRANSCEIVER
GM800
Contact: Lily Zhang
E-mail:sales@allshipparts.com
E-mail:info@allshipparts.com
WeChat:Allshipparts
Reliable Performance for MF/HF Long Distance Communication
·
This model is currently being recertified to the latest
MED Directive.
Please consult with your local regulatory authorities regarding
installation and/or “Wheelmark” requirements.
Satisfies SOLAS Carriage Requirements
The GM800 meets the GMDSS (Global Maritime Distress and Safety System) VHF and MF/HF radio requirements as required for SOLAS regulated commercial vessels engaging in international voyage. The radio meets the MED, "wheel mark" requirements for European merchant ships.
Meets Strict Environmental Requirements
The GM800 have passed rigorous environmental testing and quality assurance processes. These radios are designed to provide reliable operation and long-lasting durability under harsh maritime environments. In fact, the controller has IPX7 protection (1 m depth of water for 30 minutes).
Meets ITU-R M.493-13 DSC
SHAPE \* MERGEFORMAT
DSC Task mode screen
The dedicated DSC watch-keeping receiver continuously scans the six distress channels in rotation. A total of 100 MMSI members for DSC calls can stored with a 10-character ID name. The DSC Multitask function shows up to seven DSC procedures. The GM800 is also capable of sending a distress relay call.
4.3 inch Wide Viewing Angle Colour Display
The 4.3 inch colour TFT LCD provides almost 180 degree wide viewing angle and displays high resolution characters and function icons. Even when the radio is installed to the instrument panel, the operator can clearly recognize the display information from various viewing angles. The night mode display ensures good readability in low light conditions.
SHAPE \* MERGEFORMAT
Menu screen
SHAPE \* MERGEFORMAT
Night mode screen
Provides Loud, Clear Audio
By adopting a new waterproof paper speaker cone, the speaker provides superior sound quality and a flat frequency response with a wide frequency range.
Unified Design User Interface
SHAPE \* MERGEFORMAT
The GM800 (MF/HF) and GM600 (VHF) have a unified design and offer consistent operation. A combination of the directional keypad and soft keys provides simple operation. Most used functions are assigned to soft keys (at the bottom of the display) for quick one push function access. The large ten-key pad enables you to smoothly enter channel numbers, MMSI numbers with ID names and so on.
|
Frequency range (Unit: MHz) |
TX |
1.6–27.5000 (ITU marine channels) |
|
RX |
0.5–29.9999 (continuously) |
|
|
DSC |
2.1875, 4.2075, 6.3120, |
|
|
Type of emission |
TX/RX |
J3E (USB/LSB*), H3E* (AM), |
|
DSC |
F1B |
|
|
Power supply requirement |
24 V DC (21.6–31.2 V) (floating ground) |
|
|
Dimensions (projection not included; W×H×D) |
Main unit |
367 × 95 × 260 mm |
|
Controller |
274 × 114 × 86 mm |
|
|
Weight (approximately) |
Main unit |
8.6 kg |
|
Controller |
760 g |
|
|
RF output power |
150W PEP into 50 Ω (at radio terminal) |
|
|
Current drain |
Transmit |
Less than 20 A |
|
Receive |
Less than 3.0 A |
|
|
Sensitivity |
J3E, A1A |
30 dBμV emf (0.5–1.599 MHz) |
|
J2B, F1B |
3 dBμV emf (1.6–2.099 MHz) |
|
|
H3E |
44 dBμV emf (0.5–1.599 MHz) |
|
|
DSC (J2B) |
0 dBμV emf |
|
|
Audio output power |
External SP |
4 W with 4 Ω load |
|
Internal SP |
2 W with 8 Ω load |
|
|
IEC 61162-1 |
Input |
GGA, GNS, GLL, RMC, FSI |
|
Output |
FSI, DSC, DSE |
|
Measurements made in accordance with EN300 373-1 for GM800.
Applicable IP Rating
|
Ingress Protection Standard |
|
|
Water (GM800 controller unit) |
IPX7 (1 m depth water for 30 minutes) |
