Kexun KL-1G/2G Relay box

Kexun KL-1G/2G Relay box

Contact: Lily Zhang
E-mail:sales@allshipparts.com
E-mail:info@allshipparts.com
WeChat:Allshipparts

Function
Relay box is used for auto telephone and batteryless telephone.
With two sets of active output，With one sets of passive contact output，Contact output normally close or rhythm is optional.

Power supply:
KL-1G DC24V
KL-2G AC220V±10%
Color: green gray（RAL 6034）
IP class: IP44
Weight: 0.64/1.0Kg
Active output capacity:
KL-1G DC24V/1A
KL-2G AC220V/1A
Passive contact load (resistance): 8A/250VAC
Passive contact maximum switchover voltage: 440VAC/125VDC
Stuffing box cable entrance hole size: 4-Φ12mm
