ENTEL LAND DT952

ENTEL LAND DT952

Product Description:

ENTEL LAND DT952

Contact: Lily Zhang

E-mail:sales@allshipparts.com

E-mail:info@allshipparts.com

WeChat:Allshipparts


Overview

This DMR446 license free portable is the latest addition to our DTEx DMR Digital Series of Intrinsically Safe radios.

The industrial grade DTEx delivers exceptionally loud audio coupled with outstanding audio clarity and the ergonomic controls are specifically designed for gloved hand use.

With a market-leading IP68 rating (2-meters 4-hours) the fully submersible, MIL-STD-810 DTEx can be depended on to withstand the most extreme and hostile of environments.

The ultra compact, fully submersible DX446E is the non-Intrinsically Safe license free DMR radio alternative.


KEY FEATURES

  • 16 Channels, 1 Zone
  • IP68 Submersible (2m, 4 hours)
  • MILSTD construction 810C/D/E/F/G
  • High capacity Li-Ion battery
  • 3 watts loudest & best clarity audio - in class
  • 2 slot simplex
  • Multiple receive groups
  • Talker alias (TX only)
  • Group calling
  • Individual calling
  • Programmable buttons
  • Gold plated accessory connector
  • Locking accessory connector
  • Accessory audio tailoring optimises audio for each accessory
  • Drag and drop end user programmer, no need to visit site

IN DEVELOPMENT

  • Personal attack button
  • Channel voice annunciation
  • Advanced voice annunciation (battery capacity etc.)
  • VOX



If you require a feature not listed above, please let us know.

Features

Environmental protection - IP68 (2 Meters for 4 hours) Entel's radios are approved to IP68 (2 Meters for 4 hours) rated construction, which means that they are dust protected and fully Submersible (even with the accessory cover removed).

MILSTD 810C/D/E/F/G Meeting MIL-STD 810C/D/E/F/G and providing commercial grade construction for tough, enduring performance. Entel's radios conform to stringent standards, enabling them to withstand the everyday rigours of shock, vibration and the corrosive effects of dust and moisture, ensuring many years of trouble free use.

Outstanding Audio Entel’s radios offer best-in-class performance with natural-sounding digital audio. Easy to read large character display

Programmable buttons - To ensure your Entel radio meets your exact need its buttons can be programmed with the exact features you need.

Gold plated accessory connector - The radios multi-pin interface and Micro-USB socket are both submersible and gold-plated to minimise any risk of damage and protect against corrosion.

Locking accessory connector - All Entel accessories incorporate a robust locking connector and the radios accessory socket has been specifically designed so that when an accessory is secured to the portable, the connection can withstand any amount of punishment; from dropping to careless misuse.

Accessory audio tailoring - Entel's radios identify the attached accessory and automatically adjust its settings ensuring the most natural and readable audio possible is delivered even with bone conductive accessories and breathing apparatus com kits.

Scan - Scan makes the radio automatically change channels for you searching for activity, when received the radio will stop on the channel until the transmission has ended. You can respond or let the radio resume scanning.

Voice annunciation – This programmable feature announces either the channel position selected or, in the case of marine models, the marine channel number (alias) – this gives further assurance to the user that they’ve selected the correct channel allowing them to focus on the task in hand.


Technical Specification

General

Frequency Range

PMR/DMR446

Channels

16

Number of Zones

1

Vocoder

AMBE+2™

Battery

CNB950E 1800mAh Lithium-Ion

Overall Dimensions (HxWxD)

138mm x 60mm x 38mm

Frequency Stability

± 1.5ppm

Operating Voltage

7.4v

Programmable Buttons

3

Analogue Channel Spacing

12.5/20/25KHz

Digital Channel Spacing

12.5KHz

Battery Endurance (5/5/90 duty cycle @ 0.5W)

Analogue 14.5 hours
Digital 18.5 hours

Transmitter

Output Power

0.5 Watt

Modulation Limiting

±2.5kHz @ 12.5kHz
±4.0kHz @ 20kHz
±5.0kHz @ 25kHz

Conducted / Radiated Spurious Emissions

Better than -36dBm

Adjacent Channel Power

Better than 60dB

Audio Distortion (typical)

3%

Receiver

Sensitivity (typical)

Analogue
-121dBm (0.2uV) for 12dB SINAD
Digital
-121dBm (0.2uV) for 5% BER

Intermodulation response rejection (ETSI)

> 70dB

Adjacent Channel Selectivity (ETSI)

> 70dB(12.5KHz) 60dB(25KHz)

Spurious Response Rejection (ETSI)

> 70dB

Audio Output Power

1-Watts

Audio Distortion (typical)

3%

Conducted Spurious Emission (ETSI)

> - 57dBm

Environmental

Ex Protection

ATEX II 2G Ex ib IIC T4 Gb

Operating Temperature

-20°C to +55°C

Storage Temperature

-40°C to +85°C

Thermal Shock, Humidity, Shock & Vibration, Packing Test, Drop Test

MIL-STD-810 C/D/E/F/G

Dust & Liquid Ingress

IP68 (2m 4h Submersible)
