Overview

The ultra durable DTEx Series sets the benchmark for next-generation on-board radios. Standard features include channel voice annunciation option, high torque ergonomic controls, designed for gloved-hand use, and industry-leading IP68 2m 4 hours submersible rating, to provide 100% reliability and usability even in the most extreme conditions.

KEY FEATURES

• IP68 Submersible (2m, 4 hours)
• MILSTD construction 810C/D/E/F/G
• Exceptionally loud audio
• High capacity Li-Ion battery
• Spare Programmable buttons
• Gold plated accessory connector
• Locking accessory connector
• Accessory audio tailoring optimises audio for each accessory
• Drag and drop programmer, no need to return radios to re-program
• Voice annunciation – can announce battery status, channel etc

Features

General

Channels - This non display VHF marine portable can be programmed with up to 16 channels.

Voice annunciation – This programmable feature announces either the channel position selected or a marine channel number (alias) – this gives further assurance to the user that they’ve selected the correct channel allowing them to focus on the task in hand.

Environmental protection to IP68 (2 Meters for 4 hours) - The DT842 offers the highest submersibility rating of any manufacturer. This protects against corrosion, withstanding total immersion in water to a depth of 2 meters for 4 hours to protect against the likely hazards encountered in extremely wet environments.

Robust accessory socket – DT842 accessory socket has been specifically designed so that when an accessory is secured to the portable, the connection can withstand any amount of punishment; from dropping to careless misuse. The rugged, multi-pin interface and Micro-USB socket are both submersible and gold-plated to minimize any risk of damage and protect against corrosion. To ensure the integrity of IS protection levels any accessory connected to the handset automatically undergoes a validation process to safeguard against non-compliant accessories being used. All DT842 accessories incorporate a robust locking connector to further safeguard the safety of the user.

Li-Ion battery technology & improved talk time – DT842 radios are supplied with the latest intelligent Lithium-Ion battery technology as standard. One key advantage of Lithium-Ion battery technology is the way it eliminates ‘memory effect’, meaning that there is no need to fully discharge your battery before recharging. As a result of this, you are assured of a full charge each and every time you take your Entel battery from its charger.

Superior Audio - DT842 portables deliver loud & crisp audio no matter what environment you are in. All of the DT842's range of accessories incorporate a robust locking plug and high-grade cable and benefit from Entel’s proprietary “Smart Speech Tailoring” technology. This automatically detects the type of accessory connected and optimizes the audio accordingly to deliver the very best performance.

Convenience

Simple onboard reprogramming app - With our free, unique and simple to use PC app, you can easily re-program a DT842 radio whilst still onboard. The user friendly app makes it easy to drag and drop a new programming file from an email to your DT842 radio(s).

This is a simple and seamless process that can be carried out by non-technical personnel.

Keylock - To avoid accidental operation, your radio's keys & controls can be locked.

Programmable channel monitor button - If you have channel protection enabled on your DT842 portable, all signals other than your own networks will be filtered out. This can be temporarily disabled allowing you to monitor all signals on your channel.

Audio Accessories & BA Support - Entel also offer an extensive range of accessories including Draegor BA, most popular for Fire Fighters is the CXR bone conductive throat and skull microphones which eliminate ambient noise, further enhanced by DT842's speech tailoring technology delivering intelligible communications first time, every time

Scan - a programmable button allows channel scanning.

Safety

ATEx IIB Approved - The DT842 ATEX certified portables meet IIB T4 - the most stringent ATEX ratings as per EU directive 94/9/EC.

Technical Specification

General

Transmitter

Receiver

Environmental
